Sand Dunes of Nili Patera in 3-D
MGS MOC Release No. MOC2-282, 24 May 2001 |
 One of the very first places photographed by the MOC at the start of the Mapping Mission in March 1999 was a field of dunes located in Nili Patera, a volcanic depression in central Syrtis Major. A portion of this dune field was shown in a media release on March 11, 1999, "Sand Dunes of Nili Patera, Syrtis Major". Subsequently, the image was archived with the NASA PlanetaryData System, as shown in the Malin Space Science Systems MOC Gallery. On April 24, 2001, an opportunity arose in which the MGS could be pointed off-nadir to take a new picture of the same dune field. By combining the nadir view from March 1999 and the off-nadir view from April 2001, a stereoscopic image was created. The anaglyph shown here must be viewed with red (left-eye) and blue (right-eye) "3-D" glasses. The dunes and the local topography the volcanic crater's floor stand out in sharp relief. The images, taken more than one Mars year apart, show no change in the shape or location of the dunes---that is, they do not seem to have moved at all since March 1999. |
|
| Previous Image More to come... | NASA/JPL/Malin Space Science Systems |
